ErgoDeck® General Purpose Solid with Gritshield®

Group
ML567



$52.27

Summary

    Bundle

    Build Yours

    ErgoDeck® General Purpose with GRITSHIELD® increases traction by 40%, and the softer compound provides additional standing comfort. The LockSafe Positive Interlocking System™ delivers secure connections. Perfect for lean manufacturing, tiles can be unlocked and reconfigured as work areas change. The optional 6" (15 cm) side safety ramps and corners have countersunk holes for semi-permanent installation.

    Quality made by Wearwell in the USA.

    • U.S. PATENT NO. D502,557; D520,650
    • Provides secure footing and anti-fatigue in slippery areas
    • Customize in 3" increments to fit any area or configuration
    • Available in Solid and Drainage version
    • Positive Interlocking System prevents separation
    • Easily replace single pieces or sections as needed to reduce costs
    • 100% Silicone Free PVC tiles provide maximum durability

    Learn more about the different versions of ErgoDeck in our blog - ErgoDeck Ergonomic Interlocking Floor Tiles – Which Version Should I Choose?

    + Read More
    Have a question? We're here to help! Give us a call.1-888-412-8317
    Putting Together Wearwell Part Numbers
    See an example of how Wearwell puts together their part numbers.
    SKUShort DescriptionColorThicknessDimensionsStock PartPriceUOM
    ML567.78x18x18CH-CS10ErgoDeck® General Purpose with Gritshield® - Charcoal, Case of 10Charcoal7/8"18" x 18"Y$710.94CS-10

    Ramps and accessories

    SKUShort DescriptionColorThicknessDimensionsList PriceStock PartUOM
    Ramp
    ML561.78x6x18BK-CS10

    ErgoDeck® Ramps - Straight section with Grit Shield, heavy-duty, use for smoother, safer surface transitions

    Black7/8"6" x 18"$310.40NCS-10
    ML560.78x6x36AL

    ErgoDeck® Aluminum Transition Ramps - Straight section high-strength, lightweight, and chemical resistant, use for smoother, safer surface transitions

    Aluminum7/8"6" x 36"$192.63YEA
    ML560.78x6x18BK-CS10

    ErgoDeck ramps for smoother, safer surface transitions

    Black7/8"6" x 18"$177.47YCS-10
    ML560.78x6x18YL-CS10

    ErgoDeck ramps for smoother, safer surface transitions

    Yellow7/8"6" x 18"$177.47YCS-10
    Outside corner
    ML561.78x6x15x15BK-CS4

    ErgoDeck® Ramps - Outside corner with Gritshield®, heavy-duty, use for smoother, safer surface transitions

    Black7/8"6" x 15" x 15"$452.72NCS-4
    ML560.78x6x15x15AL

    ErgoDeck® Aluminum Ramps - Outside corner, high-strength, lightweight, and chemical resistant, use for smoother, safer surface transitions

    Aluminum7/8"6" x 15" x 15"$192.63YEA
    ML560.78x6x15x15YL-CS4

    ErgoDeck® Ramps - Outside corner, heavy-duty, use for smoother, safer surface transitions

    Yellow7/8"6" x 15" x 15"$258.83YCS-4
    ML560.78x6x15x15BK-CS4

    ErgoDeck® Ramps - Outside corner, heavy-duty, use for smoother, safer surface transitions

    Black7/8"6" x 15" x 15$258.83YCS-4
    Inside corner
    ML561.78x6x9x9BK

    ErgoDeck® Ramps - Inside corner with Grit Shield, heavy-duty, use for smoother, safer surface transitions

    Black7/8"6" x 9" x 9"$114.30NEA
    ML560.78x6x9x9AL

    ErgoDeck® Ramps - Aluminum inside corner, heavy-duty, for smoother, safer surface transitions

    Aluminum7/8"6" x 9" x 9"$192.63YEA
    ML560.78x6x9x9BK

    ErgoDeck® Transition Ramps - Inside corner, heavy-duty, for smoother, safer surface transitions

    Black7/8"6" x 9" x 9"$65.34YEA
    ML560.78x6x9x9YL

    ErgoDeck® Ramps - Inside corner, heavy-duty, for smoother, safer surface transitions

    Yellow7/8"6" x 9" x 9"$65.34YEA
    Parameters of Category: Specifications - General
    EnvironmentWet, Oily, Slippery
    TypeAnti-Fatigue Flooring
    Customization LevelC3 - Full Custom (Length, Width, Shape)
    Solid or DrainageSolid
    CompoundPVC
    Recycled>80%
    Warranty1 Year
    WARNING

    Warning Symbol WARNING: This product can expose you to chemicals including Di(2-ethylhexyl) phthalate, which is known to the State of California to cause cancer and Di-isodecyl phthalate, which is known to the State of California to cause reproductive harm. For more information, go to www.P65Warnings.ca.gov.

    Test Specification & Results
    PropertyTest / Result
    Flammability MVSS 302 / 'A'; Rating
    Taber Abrasion ASTMASTM D 3884 / 1% loss
    Temperature Range 0 to 120 F
    Coefficient of Friction ASTM F1677-05 / Dry: COF = 1.1 / Wet: COF = .93
    Compression Deflection Not Available
    Tear Strength Not Available
    ESD Rating Not Available
    Dielectric Strength Not Available

    Key

    • A = Performs well
    • B = Slightly affected
    • C = Moderately affected
    • D = Highly affected
    • U = Not recommended
    • NT = Not tested
    Chemical Urethane Nitrile PVC CFR SBR Natural Rubber
    Acetone U U U C C C
    Animal Fats NT A C U U U
    Bleach Solution (10% Dilute) NT B B C C C
    Boric Acid B A A A A A
    Brake Fluid U A B D D D
    Brake Fluid (Silicone Based) U A B A B B
    Chlorine Solution (3% Dilute) C A B C C C
    Citric Acid NT A C C C U
    Cutting Fluid (Mineral Oil Based) U B B B C D
    Diesel Oil U A B U U U
    Ethylene Acetate NT U NT U U U
    Ethylene Glycol B A A A A A
    Hydraulic Oil (Petroleum) U A B D D D
    Hydrochloric Acid Cole (37% Dilute) U C C B B B
    Isopropyl Alcohol A B A B B A
    Lacquer Solvents U U U U U U
    Lindol (Hydraulic Fluid) NT U NT U U U
    MEK U U U U U U
    Mineral Oil C A B A B U
    Naptha NT C U U U U
    Napthlene U U U U U U
    Petroleum U C B D D D
    Salt Water A A B B B C
    Tolulene U U U U U U
    Transmission Fluid (Type A) U B A C U U
    Trichloroethane U U U U U U
    Vegetable Oil C A B C C C
    Write Your Own Review
    You're reviewing:ErgoDeck® General Purpose Solid with Gritshield®
    Your Rating

    Q: What are the benefits of using anti-fatigue flooring?

    A: Anti-fatigue flooring is designed to offer a wide range of benefits to employees and employers. Anti-Fatigue flooring can increase worker productivity, reduce slips, trips and falls and improve the overall health of your employees.


    Q: How does anti-fatigue flooring improve overall health of my employees?

    A: Standing long-term, especially on hard, unforgiving concrete leads to lower back pain, swelling of joints and poor circulation that can lead to varicose veins. Standing on anti-fatigue flooring allows for continuous muscle movement which leads to increased blood flow to the legs, feet and back. Continuous blood circulation reduces fatigue, alleviates back pain and reduces swelling.


    Q: How does anti-fatigue flooring increase employee productivity?

    A: Fatigue eventually leads to lack of focus and concentration on the task at hand. Anti-fatigue flooring reduces worker fatigue allowing them to remain focused on the job at hand.


    Q: What if one tile gets damaged?

    A: Simply remove it and replace with a new tile.


    Q: How do you connect a ramp to the side of the tile that has connectors?

    A: Simply cut off the interlocks on the ramp.


    Q: What is meant by "customizable in 3" increments"?

    A: Unlike other modular tiles available in the market, our LockSafe connection can be cut every 3" without losing the ability to connect to adjoining tiles.


    Q: How do I cut ErgoDeck tiles?

    A: ErgoDeck is a robust product. While it can be cut with a utility knife, we suggest a band saw or similar cutting equipment for larger installations.


    Q: Do I need to use adhesives or special tools?

    A: One of the biggest benefits of the LockSafe system is a secure, dependable connection that snaps together and holds tight in-use, but zips apart for reconfiguration or replacement! No tools are necessary for the assembly or disassembly, however, a rubber mallet is sometimes used in installation to quickly "lock" the connectors. Alternatively, they can be "locked" by walking along the edges of each tile.


    Q: What does “general purpose” mean?

    A: General Purpose is intended to be used in areas with heavy foot traffic. We manufacture ErgoDeck General Purpose using the same mold as that of our Heavy Duty product but with a softer, lower durometer material for greater anti-fatigue benefit.


    Q: Can I use it over grating or catwalks?

    A: General purpose is a softer compound intended for ergonomics over solid surfaces. For grating, we suggest using our ErgoDeck Heavy-Duty or Cleated products.


    Q: What is GRITSHIELD?

    A: GRITSHIELD is our own formulation of dependable traction using clear, recycled silica for sure-footedness in slippery areas. The clear property allows GRITSHIELD to be used over any color product, including yellow ramps!


    Q: Can it be power washed?

    A: We don't suggest power washing any gritted product. If your cleaning protocol requires pressure washing we suggest using our Cleated ErgoDeck products.


    Q: I have a large, unique area to cover. How do I know how much product to order?

    A: If you need help determining exactly how many tiles and how many feet of edging
